Leica SP8 Spectral Confocal Microscope

This is an inverted confocal microscope with five filter-free spectral and individually regulatable channels including four standard PMT detectors and one high-sensitivity HyD detector with photon counting capacity. The scanner also includes both standard galvo scan mirrors and an optional 8 KHz resonant scanner for high speed imaging. Use of an acusto-optical beamsplitter (AOBS) instead of traditional dichroic mirrors makes this microscope also suitable for reflected light microscopy applications. The instrument is housed in the Bioscience Electron Microscopy Laboratory located in the Biology and Physics Building (BPB), room G10. This microscope was acquired with a NIH shared instrumentation grant. Manuscripts including data from the Leica SP8 confocal should included an acknowledgement of NIH grant S10OD016435 awarded to Akiko Nishiyama. Specifications: Microscope: Inverted Stand DMI 6000 Motorized x-y stage Super Z Galvo stage insert Lasers: 405 nm Diode laser Argon (458, 488, 514 nm) 561 nm DPSS laser 633 nm HeNe laser Scanners: Continuously adjustable galvo scanner (1-1800 Hz) Resonant scanner (8000 Hz) – 28 fps at 512 x 512 Objective Lenses: 10x/0.30 HC PL FLUOTAR 20x/0.75 HC PL APO IMM CORR CS2 40x/1.30 HC PL APO OIL CS2 63x/1.40 HC PL APO OIL CS2 100x/1.40 HCX PL APO OIL CS Detectors: Four PMTs One HyD All filter-free spectral and individually regulatable detectors Transmitted light brightfield detector Software: LAS X for image acquisition, processing, and quantification
